Specification

Model No.:
MT50Q/MT100Q



Installation method:
Horizontal, vertical

(accessories: angle steel, light steel keels, bolts, hoops, rivets and steel wire)

Installation location:
Ceiling

Colour:
Selectable

Weight:
9.8kg/m2

Consumption:
Refer to acoustic design

Fire protection performance:
Grade A

Structure:
Surrounding aluminium alloy frame, perforation rate 32% with
environmental friendly sound absorption cotton filled inside

Common specification:
2400×1200×50/100mm (upper limits of plane dimensions)

Application:
Stadiums, large halls, airports, metro stations, etc.
